Description
- Wide components range: High speed modular heads apply to LED 3014/3020/2835/5050 and resistors, capacitors, bridge rectifiers etc.
- Unique design component leaking detection and individual component refill function. Recognition camera record the component leaking position of PCB, and fill the missing component accordingly.
- Ultra high speed capacity: 500,000 CPH
- Intelligent electric feeder,supporting high-speed machine series.
- Adjust the conveying platform according to various roll to roll strip, range 250±10 mm, the max length range is 1M per cycle.
- The distance of feeder station can be flexibly adjusted to achieve group picking and group placing, so as to realize the function of two time picking and once placing.
- The range of feeder station is double of placement four kinds of materials at the same time.
- Automatic production with identification date, correction and fill missing component automatically.
- Flight recognition camera, no pause to detect the presence or absence of components, component adsorption state, prevent placement errors.
- The clamping rod is driven by the air cylinder to correct the materials taken by mounting head.
|
Model |
HT-T9 |
|
Dimension |
3100*2300*1550mm |
|
Model |
T9-2S |
|
Dimension |
(L)3454*(W)3035*(H)1777 mm |
|
Total weight |
3100 kg |
|
PCB size |
250(±10)mm* Any length |
|
Power consumption |
9.6 KW |
|
No. of feeder station |
Double side: 136 PCS (Single side: 68 PCS) |
|
No. of nozzles |
Double side: 136 PCS (Single side: 68 PCS) |
|
No. of feeders station |
68PCS |
|
No. of head |
68PCS |
Eton has participated in many exhibitions of foreign countries , such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc and trading with more than 20 countries. Furthermore, we have took part in our domestic large exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Maintenance period 1 year
One year warranty during warranty any parts that need to be repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON, so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in different cities every year, at the same time, we will visit local clients and support our service and collect feedback on customer suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And share the updated news with our clients
On-site service
We have some official site in India as Mumbai and New Delhi, also have site in Egypt, Turkey that can provide service timely with our engineers.
According to your needs, dedicated senior engineer will come to your factory for free install and training you how to operate the machine.
As to the part of shipping and delivery, there are three ways for your reference, and different way is for different situations:
-
- Q. Can you accept CIF as the quoted price?
- A. We usually accept EXWas the quoted price.
- Whether you have professional engineers for installation of the machine in India?
- Yes, we have professional engineers in India to provide considerable service to our clients.
- Q. How was your services？
- A. We ensure our clients to enjoy an optimal experience of the service of communication and relevant needs of the machine for installation, maintenance and free up- grade.
- Q. Can you accept D/P or D/A as the payment term?
- A. For our regular payment terms, we usually use T/T.
