Description
Introduction of pick and place machine E8D-600
HT-E8S is middle speed multi-functional pick and place machine. For higher speed pick and place machine we have HT-E8D. From the machine dimension, HT-E8D is bigger than HT-E8S, but the most different between HT-E8S and HT-E8S is two mounting heads while HT-E8S is only one.
we can see that the main guide rail of HT-E8D are high-end magnetic linear motor and servo motor. Similar like the HT-E8S. But There are two times numbers of cameras , mounting heads, feeder stations, computers, guide rail than HT-E8S. It makes the speed is two times of HT-E8S. And can produce two products at same time.
Also while the one side stop working , the other side will continue working, they are control independently. Very intelligent.
Besides, The structure of HT-E8D can save space and labor and cost than you buy two sets of HT-E8S. So if there is client who is looking for high speed multi-functional pick and place machine, don’t miss this model. It is really amazing.
Techniacal Parameter
|
Model |
HT-E8D-600 |
|
Dimension |
|
|
Length |
1950mm |
|
Width |
2250mm |
|
Height |
1650mm |
|
Total Weight |
2200kg |
|
PCB |
|
|
PCB Length Width |
Max:600*300mm Min:100*100mm |
|
PCB Thickness |
0.5-5mm |
|
PCB Clamping |
Adjustable pressure pneumatic |
|
Mounting Mode |
Group picking and separate placing\separate picking and separate placing |
|
O.S. |
|
|
System |
Windows7 |
|
Software |
R&D independently |
|
Display |
Touch screen monitor |
|
Input Device |
Keyboard, Mouse |
|
Vision System |
|
|
No. of Camera |
4 sets of imported camera |
|
Vision for the flight identification, MARK correction |
|
|
Mounting Precision |
±0.04mm |
|
Mounting Height |
<15mm (Automatic Changing) |
|
Mounting Speed |
90000 CPH |
|
Components |
LED , capacitors, resistors, IC,shaped components, etc. |
|
Components Space |
0.2mm |
|
No. of Feeders Station |
48 PCS |
|
No. of nozzles |
24 PCS |
|
Power |
380AC 50HZ |
|
Power Consumption |
8 KW |
|
Operating Environment |
23℃±3℃ |
|
Conveyor transmission |
Max length :600 mm |
|
Transmission Speed |
＞1000mm/sec |
|
Transmission Direction |
Both direction (option) |
|
Transmission Mode |
Auto online drive |
|
Air supply |
0.4-0.6mpa (4-6kgf/cm2)300N/min |
|
Electrical control |
Independent research and development by ETON |
|
Motion control card module 2 set |
Independent research and development by ETON |
|
X,Y,Z Axis Drive way |
High-end magnetic linear motor + Servo motor |
|
Feeding way |
Electric feeder with double motor |
EXihibition
Our company participates in many exhibitions at home and abroad every year,
You will see ETON’s booth in some well-known large-scale exhibitions in China, including large-scale exhibitions held in Shenzhen, Guangzhou, Chongqing, Shanghai and other places.
Foreign exhibitions include exhibitions in more than 20 countries including Mumbai, Delhi, Egypt, Turkey, and Vietnam.
FAQ
Q: How is the training?
A: After purchasing our products, you can send your engineers to study in our factory, or we can send our engineers to yourfactory to train your staff for you .
Q: Do you have a product certification certificate?
A: Our products have CCC, CE, SRIA certification.
Q: How about the after-sale service? How about the warranty?
A: We have a team of professional engineers to solve your problems. Any parts that require repair and replacement are free ofcharge during the warranty period. We can also provide you with training and on-site installation, and support remote control of the machine, the machine uses Chinese and English interface, very easy to operate.
