Multifunctional high quality SMT machine

  • Single module magnetic linear motor multifunctional pick and place machine.
  • Mounting components: LED chip, capacitors,resistors,lens,IC,shaped components, etc.
  • Component:Min.size 0402 Max.height 15mm
  • Application:Power drive ,electric board,lens,DOB bulb,linear bulb,household appliance,etc.

Description

Multifunctional high quality SMT machine

Machine main features

  • Single module magnetic linear motor multifunctional pick and place machine.
  • Mounting components: LED chip, capacitors,resistors,lens,IC,shaped components, etc.
  • Component:Min.size 0402 Max.height 15mm
  • Application:Power drive ,electric board,lens,DOB bulb,linear bulb,household appliance,etc.



Multifunctional high quality SMT machine

Parameter

Dimension 2550*1650*1550mm
Weight 1700KG
PCB size Max.1200*500 Min.100*100mm
PCB thickness 0.5-5mm
PCB clamping Adjustable pressure pneumatic
Mounting speed 45000CPH
No.of feeder 28PCS
No.of head 12PCS

Application

Apply to the electric board, LED flexible strip,power drive,tube,lens,etc.

Component: Min. size 0402 Max. height 15mm.

Application: Power drive,electric board,lens,DOB bulb,linear bulb,household appliance,etc.

Packaging

All machines are packed with vacuum and wooden packing

Step1:Film packaging.

Step2:Vacuum packaging.

Step3:Wooden box packaging

You can trust us, because we have professional and standard packaging to protect the machine.

FAQ

Q: How can you make sure that the products won’t be damaged or wet?

A: We take multiple measures to protect the products. They are first packing with individual. We put them into a carton and wrapped with plastic film and sealed with tape to keep the cartons in position and protect them from water.



Q: How is the breakdown rate of machine?

A: our machine is very stable,the breakdown rate is less than 0.001.



Q: What kind of machine will provide besides pick and place machine ?

A: ETON as the largest manufacturer of SMT machine in China, we provide whole SMT line, such as reflow oven, printer, conveyor, pick and place machine, Loader, Unloader, etc.



Q:What are your advantages?

A: Our company stick to five level management policy: sincere business, focus on R&D, manufacturing intentions, considerate service, customer trust.



Q:If my order is very urgent, how long you can proceed?

We have helped many clients with their urgent demand. If your order is urgent, please check with our specialists to see if we can help.



Q:How are the products packed for sea shipment?

Most of the products have their unique packing, Then we put them into a carton. The cartons are sealed with tape.
