Description
Machine main features
- Adopt High speed multi modular head, apply to ultra small chip 0201~40*40 mm large chip, widercomponent range;
- Brand new flight vision camera: Improve recognition performance, size up to 40*40 mm, apply to BGA or CSP etc;
- Vacuum sensing device: Each placement head with independent detection function, which improves the stability of the equipment and the reliability of the product;
- Ultra high speed capability: Optimum speed reach 80000 CPH;
- Brand new self-developed high precision placement head;
- Combine highaccuracy Mark recognition camera with fixed flight vision camera, ensure placement accuracy;
- The placement head adopt independent vacuum detection, improve placement performance;
- Off-line programming, save time of changeover cycle;
- Software AI intelligent learning function and automatic optimization function.
- Two gantry, 10 spindles82 Gantry, total 20 spindles;
- Flexible PCB handling capabilities, double rail, both gantry can mount the same large PCB at the same time, realizing flexible production.
Machine main parameter
|
Model |
YT-202S |
|
PCB size |
Max size: 500*450 mm(Single side) 500*300 mm(Double side) Min size: 50*50 mm |
|
PCB thickness |
0.5-4.5 mm |
|
Rail |
2 rail, 2 gantries(rail 1，4 are fixed rail) |
|
Camera |
Bottom vision camera recognition, Vision alignment + Mark camera |
|
PCB clamping |
Cylinder clamping, track width adjustable |
|
Production management MES system |
Customized (Option) |
|
Off-line programming |
Available |
|
Camera |
Head flight vision recognition component Vision alignment + Mark correction |
|
Repeat precision |
±0.02 mm |
|
Mounting height |
≦20 mm |
|
Optimal speed |
80000 CPH |
|
Component range |
Min 0201~40*40 tape reel packages and IC tray feeder etc. |
|
No.of heads |
Double side: 20 pcs Single side:10 pcs |
|
Feeding way |
Intelligent double head feeder |
|
X,Y,Z, Axis drive way |
High-end magnetic linear motor + Servo motor |
Market
Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:
SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.
Our Exhibitions
Eton has participated in many exhibitions of foreign countries , such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc and trading with more than 20 countries. Furthermore, we have took part in our domestic large exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Service
Maintenance period 1 year
One year warranty during warranty any parts that need to be repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON, so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in different cities every year, at the same time, we will visit local clients and support our service and collect feedback on customer suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And share the updated news with our clients
On-site service
We have some official site in India as Mumbai and New Delhi, also have site in Egypt, Turkey that can provide service timely with our engineers.
According to your needs, dedicated senior engineer will come to your factory for free install and training you how to operate the machine.
Shipping and Delivery
As to the part of shipping and delivery, there are three ways for your reference, and different way is for different situations:
Land transportation: suitable for inland countries and it is affordable;
Air freight: for urgent good, and it is the most expensive transportation way;
Shipping: It’s suitable for heavy goods, and the convenience and lower cost of shipping which is easy for clients to accept the arrival time of the goods.
FAQ
- What services can you provide?
- We provide whole line solution for our clients;
- We have local engineers in India, Egypt, Turkey. As long as you buy the machine, we will arrange engineers to install, debug and training you for free, until you learned how to operate the machine, our service is very convenient;
- We also have Chinese engineers which provide online services to operate the machine to solve the problems with the machine;
- We will visit our clients for twice a year to operate the machine and view the status of the machine;
- Our clients enjoy a free up grade of the machine.
- Does your machines have quality certificates?
- We are high-tech enterprise with CE, SIRA, CCC , ISO awarded as”Well-know brand” and many technology patents, and have rich experience(more than 11 years) in LED light production line program.
- What is your actual speed of your products?
- For the actual speed of the machine which is constrained by many factors,that relatedto the number of the components, the time to send PCB board and receive the board that will have influence on the speed when in production, and is decide for the actual products and needs.
- Can you accept CIFas the quoted price?
- We only accept EXW as the quoted pricefor it is convenient and lower cost for both sides.
- Can I go and see if you have sold the equipment to India?
- Yes, we have sold our machine in India, but for the fact we can’t decide it for my customer, but I will try to contact my customer. Hope you can understand, because no one wants their competitors to visit their manufacturing site.
- How many products can your machine make per day?
- The capacity of our machine is according to the real products, and the number of components on your PCB board that is important factor to figure out the actual speed of our machine with your products.
