- Adopt High speed multi modular head, apply to ultra small chip 0201~10*10mm large chip, widercomponent range;
- Vacuum sensing device: Each placement head with independent detection function, which improves the stability of the equipment and the reliability of the product;
- Ultra high speed capability: Adopt high-end magnetic linear motor, servo system and multi function modular head, the capacity increased by 25% compared with traditional machine, optimum speed reach120000 CPH;
New design mounter Min 0201, 10*10mm packages and IC
Description
Machine main features
- Adopt High speed multi modular head, apply to ultra small chip 0201~10*10mm large chip, widercomponent range;
- Vacuum sensing device: Each placement head with independent detection function, which improves the stability of the equipment and the reliability of the product;
- Ultra high speed capability: Adopt high-end magnetic linear motor, servo system and multi function modular head, the capacity increased by 25% compared with traditional machine, optimum speed reach120000 CPH;
- Brand new self-developed high precision placement head;
- Combine highaccuracy Mark recognition camera with fixed flight vision camera, ensure placement accuracy;
- Docking Cart: Double side docking cart slot 32 PCS, tape reel package:64 PCS(Single docking cart slot 16 PCS, tape reel package:32 PCS)
- Smart Double-Head tape feeder: Support YT series double head intelligent electric tape reel feeder, by optically correcting the feeding position of the component, it can achieve stable, accurate and high-speed feeding;
- The placement head adopt independent vacuum detection, improve placement performance;
- Off-line programming, save time of changeover cycle;
- Software AI intelligent learning function and automatic optimization function.
- Two gantry, 20 spindles*2 Gantry, total 40 spindles;
- Flexible PCB handling capabilities, double rail, both gantry can mount the same large PCB at the same time, realizing flexible production.
Machine main parameter
|
Model |
YT-402 |
|
PCB size |
Max size: 500*450 mm(Single side) 500*300(Double side) Min size: 50*50 mm |
|
PCB thickness |
0.5-4.5 mm |
|
PCB clamping |
Cylinder clamping, track width adjustable |
|
Rail |
2 rail, 2 gantries(Rail 1,4 are fixed rail) |
|
Software |
R&D independently |
|
Production management MES system |
Customized (Option) |
|
Off-line programming |
Available |
|
Camera |
Head flight vision recognition component Vision alignment + Mark correction |
|
Repeat precision |
±0.02 mm |
|
Mounting height |
≦6 mm |
|
Position mode |
Optical |
|
Optimal speed |
120000 CPH |
|
Component range |
Min 0201~10 mm packages and IC etc. |
|
Position mode |
Optical |
|
No.of heads |
Double side:40 PCS Single side:20 PCS |
|
Feeding way |
Intelligent double head feeder |
|
X,Y,Z Axis drive way |
High-end magnetic linear motor + Servo motor |
A whole semi automatic line which needs several devices for a whole semi production, as semi auto stencil printer machine, conveyor, pick and place machine and reflow oven etc.
The blowing is the function of each machine:
- Semi auto stencil printer is aim of leaking solder paste or patching adhesive onto the solder pad of PCB to prepare for the welding of components;
- Pick and place machine is to mount light beads or other surface mounted components at the designated position of PCB board；
- Reflow oven is to melt the solder paste to fix and bond the components and PCB board.
- Conveyor is used for the connection between SMT production lines, as well as buffering, testing, testing PCB boards or manual plug-in of electronic components;
As an experienced manufacturer in SMT machine, we obtained a number of intellectual property technologies, including 9 invention patents, 112 practical patents, 12 software copyrights, with our won R&D department for production and inspection. And also earned the oversea certificates as CE, CCC, SIRA, etc.
Eton has participated in many exhibitions of foreign countries , such as India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc and trading with more than 20 countries. Furthermore, we have took part in our domestic large exhibition, like Guangzhou Guangya Exhibition, Shanghai Munich Exhibition, Chongqing LED light Exhibition, etc.
Maintenance period 1 year
One year warranty during warranty any parts that need to be repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON, so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in different cities every year, at the same time, we will visit local clients and support our service and collect feedback on customer suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And share the updated news with our clients
On-site service
We have some official site in India as Mumbai and New Delhi, also have site in Egypt, Turkey that can provide service timely with our engineers.
According to your needs, dedicated senior engineer will come to your factory for free install and training you how to operate the machine.
- Is the machine easy to operate?
- Yes, our machine is very intelligent and easy to operate, like the intelligent phone, also the software is made by our company, so we know how to make it more intelligent and operate friendly.
- Can I go and see if you have sold the equipment to India?
- Yes, we have sold our machine in India, but for the fact we can’t decide it for my customer, but I will try to contact my customer. Hope you can understand, because no one wants their competitors to visit their manufacturing site.
- How many hours does the machine can operate per day?
- Machine can work whole day. But for longer using life, we suggest you to have 1 hour or 2 hours off per day.
- What is your merits of the machine to others production?
- Initially, we have a strong R&D department for studying our productions, and our clients can enjoy free up-grade of the machine to get latest information about technology and equipment, besides, we have a 52000 square meters industrial park to serve the production, assembly, and commissioning of our machines.
