Description
Technical parameter
|
Description |
This equipment is used to transfer the circuit board in the production line |
|
Transport height |
900±20 mm |
|
Power consumption |
Single-phase AC 110 ~ 220 V (optional), up to 50 volt amperes |
|
Transport speed |
0.5 ~ 20 meters per minute (or customer specified) |
|
Conveyor belt type |
4 mm wide flat belt |
|
Steel frame structure, rail length |
L=500 |
|
Width adjustment range |
50～350 mm |
|
PCB size |
500*350 mm |
|
Transmission |
5 MM flat belt conveyor |
|
Speed |
Adjustable from 0.5 to 9 m/min |
|
Motor |
One set of 25 W stepper motor |
|
Control |
Industrial control panel |
|
Transmission Direction |
Single (left → right ) |
|
One section of control, two Sensors |
|
SMT automation equipment LED light conveyor
Product features
1.The movable working table, Visible Board document and lighting rack are arranged on the basis of the conveyor;
2.The lighting brightness, operation height and other user-friendly design, the operation is more efficient, convenient and practical;
3.Green flat imported anti-static transmission belt, durable, easy to replace;
4.Sheet metal weighted structure, overall stable, not easy to shift;
5.PLC control system, through SMEMA communication.
Product optional features
1.Two-segment transmission or multi-segment transmission (each segment length should be at least 0.5 meters);Two sections of independent adjustment width mode;
2.Install cooling fan, blocking cylinder, shelving table, dust cover and other additional configurations;
3.Special program requirements such as checking function with scanner and NG/OK communication function with AOL.
Exhibitions
ETON every year will actively participates in various domestic and foreign exhibitions. The purpose is to let our products show up in front of the customers who are from all around world. the domestic exhibitions include Guangzhou Light Asia Exhibition, Shanghai Munich Exhibition, Chongqing LED exhibition; the international exhibitions include India Mumbai exhibition, Pakistan exhibition, Egypt exhibition, Turkey exhibition and so on.Our production have exported to more than 20 countries and regions, including South Korea, India, Egypt, Turkey, Russia etc.
Maintenance period 1 year
One year warranty, during warranty, any parts that need to be repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON, so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in different cities every year, at the same time, we will visit local clients and support our service and collect feedback on customer suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And share the updated news with our clients.
